Fabric Adapter

contractforge-fabric is the Microsoft Fabric Lakehouse adapter for ContractForge.

The current adapter is a stable supported notebook-first Fabric Lakehouse surface. It can render, deploy and run generated Fabric notebooks for the documented Lakehouse subset, and it writes ContractForge control-table evidence into Fabric Lakehouse Delta tables.

Validated Scope

• Package: independent contractforge-fabric wheel.
• Subtarget: fabric_lakehouse.
• Runtime path: Fabric REST preflight, generated Notebook deployment, Notebook run submission and terminal job classification.
• Sources:
  • table, view, SQL and Lakehouse file sources for notebook rendering;
  • Lakehouse text, orc, avro and xml file sources with live Fabric source-expansion evidence;
  • internal OneLake shortcut reads with live Fabric shortcut creation and source-expansion evidence;
  • public/no-auth bounded rest_api with live USGS REST/GeoJSON bronze-to-gold evidence;
  • public/no-auth http_json, http_csv and http_text with live Fabric source-expansion evidence;
  • authenticated bounded REST with Basic auth, bearer token, API-key and OAuth client-credentials placeholders, plus authenticated http_json and http_csv with Basic auth, bearer token and API-key placeholders, {{ secret:scope/key }} secret placeholders and Azure Key Vault runtime resolution, with live Fabric source-expansion evidence.
  • endpoint-enforced Basic, bearer and API-key auth on http_text, with live Fabric source-expansion evidence.
  • SQL Server/Azure SQL JDBC and PostgreSQL JDBC with Basic auth, {{ secret:scope/key }} password placeholders and Azure Key Vault runtime resolution, with live Fabric source-expansion evidence.
  • Azure Blob CSV object storage through a Fabric Spark-readable extensions.fabric.source_runtime_path binding. Public Blob and direct private Blob with a Key Vault-backed storage account key both have live Fabric source-expansion evidence.
  • External Azure Blob shortcut reads through native Fabric shortcut creation and a Fabric AzureBlobs cloud connection with Key credentials, with live Fabric source-expansion evidence.
  • External ADLS Gen2 shortcut reads through native Fabric shortcut creation and a Fabric AzureDataLakeStorage cloud connection with Key credentials, with live Fabric source-expansion evidence.
  • External Google Cloud Storage shortcut reads through native Fabric shortcut creation and a Fabric GoogleCloudStorage cloud connection with Basic HMAC credentials, with live Fabric source-expansion evidence.
  • External Amazon S3 shortcut reads through native Fabric shortcut creation and a Fabric AmazonS3 cloud connection with Basic IAM user credentials, with live Fabric source-expansion evidence.
  • External S3-compatible shortcut reads through native Fabric shortcut creation and a Fabric AmazonS3Compatible cloud connection with Basic IAM user credentials, with live Fabric source-expansion evidence.
  • ADLS Gen2, Amazon S3 and Google Cloud Storage Iceberg table shortcut reads through native Fabric shortcut creation under Tables, Fabric Iceberg-to-Delta virtualization and source.type: iceberg_table, with live Fabric source-expansion evidence.
  • Confluent Cloud Kafka bounded replay and checkpointed available-now catch-up with Key Vault-backed SASL configuration, with live Fabric source-expansion evidence.
  • Azure Event Hubs through its Kafka-compatible endpoint with checkpointed available-now catch-up and Key Vault-backed SASL configuration, with live Fabric source-expansion evidence.
• Write modes: append, overwrite, upsert, hash_diff_upsert, historical and snapshot_reconcile_soft_delete.
• Quality: required columns, not-null, unique keys, accepted values, minimum rows, max-null-ratio and expression gates.
• Shape and transforms: JSON parsing, array explode/explode_outer, column projection, flatten, cast, standardize, derive, composite keys and deterministic deduplication.
• Evidence: live control-table probes validate runs, errors, quality, schema, source metadata, lineage, explain, state, operations, annotations and access review evidence.

Evidence

The main evidence manifests are:

• Fabric USGS REST E2E smoke
• Fabric stable-surface evidence
• Fabric platform parity report
• Fabric source-expansion stable-scope decision
• Fabric project deploy-only smoke
• Fabric OneLake data access role smoke
• Fabric OneLake row/column policy smoke
• Fabric deployment pipeline read probe
• Fabric deployment pipeline lifecycle smoke
• Fabric deployment pipeline stage promotion smoke
• Fabric HTTP JSON source smoke
• Fabric HTTP CSV source smoke
• Fabric HTTP text source smoke
• Fabric Lakehouse text source smoke
• Fabric Lakehouse file formats source smoke
• Fabric OneLake shortcut source smoke
• Fabric authenticated REST source smoke
• Fabric authenticated REST variants source smoke
• Fabric authenticated REST OAuth source smoke
• Fabric authenticated HTTP JSON source smoke
• Fabric authenticated HTTP JSON variants source smoke
• Fabric authenticated HTTP CSV variants source smoke
• Fabric authenticated HTTP text Basic source smoke
• Fabric authenticated HTTP text bearer source smoke
• Fabric authenticated HTTP text API-key source smoke
• Fabric SQL Server JDBC source smoke
• Fabric PostgreSQL JDBC source smoke
• Fabric Azure Blob source smoke
• Fabric private Azure Blob source smoke
• Fabric external Azure Blob shortcut source smoke
• Fabric ADLS Gen2 shortcut source smoke
• Fabric GCS shortcut source smoke
• Fabric external Amazon S3 shortcut source smoke
• Fabric S3-compatible shortcut source smoke
• Fabric Iceberg table shortcut source smoke
• Fabric ADLS Iceberg table shortcut source smoke
• Fabric GCS Iceberg table shortcut source smoke
• Fabric Confluent Kafka bounded source smoke
• Fabric Confluent Kafka available-now source smoke
• Fabric Event Hubs Kafka available-now source smoke

Kafka bounded and available-now paths, including the Event Hubs Kafka-compatible available-now path, have live Fabric source-expansion evidence.

The stable-surface suite is contract-only and uses SQL sources to isolate runtime/write/evidence semantics from external connector availability. The USGS project validates the public REST source path from bronze to silver to gold.

Runtime Prerequisites

• Microsoft Fabric workspace on supported Fabric capacity.
• Workspace contributor/read/write/execute permissions for Notebook items.
• A Lakehouse item configured in the environment.
• A default Spark pool that fits the capacity. In the validated FTL4 workspace, a single-node Small custom pool was required to avoid TooManyRequestsForCapacity.
• Azure CLI authentication for the tenant used by the workspace.
• For authenticated HTTP/REST drafts, Azure Key Vault access from the Fabric notebook runtime through notebookutils.credentials.getSecret, with environment.secrets.vault_url or environment.secrets.scopes.<scope> configured.
• For object-storage drafts, a Fabric-readable source path declared through extensions.fabric.source_runtime_path, such as a reviewed Lakehouse shortcut, staged Lakehouse file path or direct Spark object-store URI. Direct private Azure Blob CSV can also declare extensions.fabric.storage_account_key_secret with a {{ secret:scope/key }} Key Vault placeholder; generated notebooks resolve the key and set Spark's fs.azure.account.key.<account>.blob.core.windows.net configuration before reading.
• For external Azure Blob shortcut drafts, a Fabric cloud connection ID is required. Validated project smokes declare this through fabric_setup.shortcuts and environment parameters such as parameters.fabric.connections.azure_blob_shortcut_connection_id.
• For external ADLS Gen2 shortcut drafts, a Fabric AzureDataLakeStorage cloud connection ID is required. The validated smoke uses Key credentials stored in the Fabric connection, and resolves parameters.fabric.connections.adls_shortcut_connection_id into fabric_setup.shortcuts.
• For external Google Cloud Storage shortcut drafts, a Fabric GoogleCloudStorage cloud connection ID is required. The validated smoke uses Basic HMAC credentials stored in the Fabric connection, and resolves parameters.fabric.connections.gcs_shortcut_connection_id into fabric_setup.shortcuts.
• For external Amazon S3 shortcut drafts, a Fabric AmazonS3 cloud connection ID is required. The validated smoke uses Basic IAM user credentials stored in the Fabric connection, and the project resolves parameters.fabric.connections.amazon_s3_shortcut_connection_id into fabric_setup.shortcuts.
• For external S3-compatible shortcut drafts, a Fabric AmazonS3Compatible cloud connection ID is required. The validated smoke uses Basic IAM user credentials stored in the Fabric connection, and the project resolves parameters.fabric.connections.s3_compatible_shortcut_connection_id into fabric_setup.shortcuts.
• For Iceberg table shortcut drafts, the shortcut must be created directly under Tables and point at an Iceberg table folder containing metadata/ and data/. The validated smokes use source.type: iceberg_table after Fabric virtualizes ADLS Gen2, Amazon S3 and Google Cloud Storage Iceberg folders as Lakehouse tables.
• For Kafka drafts, SASL configuration through a {{ secret:scope/key }} Key Vault placeholder. The validated bounded Confluent Kafka path uses Spark's batch reader with starting_offsets: earliest and ending_offsets: latest; the validated available-now path uses Spark Structured Streaming with trigger(availableNow=True) and a declared checkpoint_location. The validated Azure Event Hubs path uses the same Kafka-compatible Spark reader shape against the Event Hubs Kafka endpoint and a Key Vault-backed JAAS configuration.
• For Fabric-native governance apply drafts, contracts must declare explicit Fabric IDs under extensions.fabric.access_apply. The adapter can plan and execute workspace role assignments through the Fabric workspaces/{workspaceId}/roleAssignments API and item sensitivity labels through the Fabric admin items/bulkSetLabels API. It can also apply explicit OneLake data access roles through the Fabric items/{itemId}/dataAccessRoles preview API when the contract provides the native Lakehouse item ID, role members and decision rules. Live evidence validates role create/list/delete for a basic Path/Action read policy and row/column constraints against a Fabric-resolved Lakehouse table, with cleanup. Generic ContractForge row-filter functions are not auto-translated into OneLake SQL predicates; contracts must declare explicit Fabric-native OneLake policy payloads for apply mode.
• For deploy-only project promotion, contractforge-fabric deploy-project renders a deterministic project deployment manifest and can create/update generated Notebook item definitions without executing the notebooks. Deployment pipeline and Git settings can be recorded in project.deployment.fabric for promotion review. Tenant-level deployment-pipeline read, create/list/delete lifecycle and stage-to-stage Notebook content promotion probes succeeded with cleanup. The stage promotion smoke promoted one generated stable-surface Notebook from the Manager workspace to a temporary target workspace, verified the target-stage item, deleted the promoted item, unassigned both stages, deleted the pipeline and deleted the temporary target workspace. Git integration and Data Factory lifecycle promotion remain outside the current notebook-first stable scope.

Stable-Final Exclusions

The following are intentionally not claimed as stable behavior:

• OAuth for HTTP-file source types. OAuth is not currently part of the HTTP-file source vocabulary;
• Private-network shortcut variants, managed identity/OAuth object-storage access, Delta Sharing, direct-catalog Iceberg variants and native Event Hubs/Fabric Real-Time/Eventstream modes beyond the validated Kafka-compatible bounded and available-now paths;
• Fabric/Purview table grants, row filters, column masks and broader metadata apply mode beyond explicit workspace role assignment, sensitivity-label and OneLake data access role APIs with explicit Fabric-native decision rules;
• concurrent lock semantics beyond generated Delta lock SQL;
• live Data Factory pipeline deployment and Git integration certification;
• adapter-wide parity beyond the documented notebook-first subset.

The shared parity report now includes Fabric in the same machine-readable scenario set used for Databricks, AWS, Snowflake, Fabric and GCP. That closes the parity reporting gap, but it does not widen the stable claim beyond the validated notebook-first subset.

CLI

Fabric follows the standardized adapter command vocabulary in Adapter CLI. Fabric-specific flags such as --max-attempts, --retry-after-seconds and preflight checks remain platform options under the canonical command names.

stabilization-report --strict-final returns zero for the documented notebook-first stable-final claim. The exclusions above remain review-required unless separate evidence is attached.

Related Docs

• Fabric platform parity report
• Fabric stable-surface evidence
• Test contracts across adapters
